Main performance characteristics of aluminum strip butyl rubber coater

1、丁基胶涂布机为中空玻璃出产的首要设备，为半主动胶条涂布机，即人工持铝距离框进行操作，将铝距离框放在传送带上，人工持铝距离框随传送带运行，当铝距离框经过传感器时，传送压轮及打胶阀将按设定程序主动运行，即气缸动作，压轮压下，压送铝距离框进行;待铝距离框抵达打胶头时开端打胶，将胶均匀地涂在铝距离框上，当距离框另一侧快要抵达压轮时，压轮抬起，离开打胶头时，胶阀主动停止打胶。

1. Butyl rubber coater is the primary equipment for insulating glass production. It is a semi-active rubber strip coater, that is, the aluminum distance frame is manually held for operation. The aluminum distance frame is placed on the conveyor belt, and the aluminum distance frame is manually held for operation with the conveyor belt. When the aluminum distance frame passes through the sensor, the transmission pressure roller and the glue valve will operate actively according to the set procedure, that is, the air cylinder acts, the pressure roller is pressed down, and the aluminum distance frame is pressed; When the aluminum distance frame reaches the gluing head, start gluing, and apply the glue evenly on the aluminum distance frame. When the other side of the distance frame is about to reach the pressure roller, the pressure roller will lift up. When it leaves the gluing head, the glue valve will stop gluing actively.

2、选用人机界面显示屏便于操作，体系以PLC为操控中心，由光电传感PLC机、中文操控终端、PLC主动转换。按钮开关等电器元件组成，功用强大、作业牢靠、操作简单主动化程度较高。

2. The human-machine interface display screen is selected for easy operation. The system takes PLC as the control center and is actively converted by photoelectric sensor PLC machine, Chinese control terminal and PLC. Button switch and other electrical components, with strong function, reliable operation, simple operation and high degree of initiative.

3、铝条丁基胶涂布机选用目前国内较大缸径?195胶缸，装胶容量大，较大极限确保连续出产时刻，进步作业效率。选用较气动增压体系，充沛确保胶头出胶压力衡定，避免了打胶粗细不匀，断胶现象。选用4段变频调速，较大极限照料操作工人熟练程度，进步作业效率。

3. What is the current domestic cylinder diameter for aluminum strip butyl rubber coating machine? 195 rubber cylinder, large rubber loading capacity, large limit to ensure continuous production time and improve operation efficiency. The advanced pneumatic pressurization system is selected to fully ensure that the glue outlet pressure of the glue head is constant and avoid uneven glue thickness and broken glue. 4-stage frequency conversion speed regulation is selected, which greatly limits the proficiency of the operators and improves the operation efficiency.

以上就是为大家介绍的有关中空玻璃加工设备的详细的介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度

The above is a detailed introduction of the insulating glass processing equipment. I hope it will help you. If you have any questions, please contact us.
