Basic process of automatic gluing

1.测宽：一次使用或铝框宽度改变后，需要对铝条进行测宽，以便传送时铝框顺利通过胶嘴。

1. Width measurement: after one use or the width of the aluminum frame is changed, it is necessary to measure the width of the aluminum strip so that the aluminum frame can pass through the rubber nozzle smoothly during transmission.

2.加热：进入自动状态后，胶嘴和胶盘要行加热，同时传送带转动，以免胶嘴温度升高后将传送带烫坏，温度高于80度以后打胶流程才会起效。

2. Heating: after entering the automatic state, the rubber nozzle and the rubber disk shall be heated first, and the conveyor belt shall be rotated at the same time to avoid burning the conveyor belt after the temperature of the rubber nozzle rises. The gluing process will not take effect until the temperature is higher than 80 ℃.

3.传送打胶：当达到设定温度后，手持铝框放在传送带上，当前端打胶光电检测到铝框时，自动涂胶过程开始。打胶光电有信号后，延时一段时间，前压轮下压，压住铝框；前压轮下压后延时一段时间，胶缸前进，胶嘴出胶。开始涂胶后，再延时一段时间，后压轮下压。打胶光电信号消失后，延时一段时间，前压轮抬起，前压轮抬起后，再延时一段时间，胶缸停止前进，同时胶嘴停止涂胶；停止涂胶后，再延时一段时间后，后压轮抬起，铝框一边涂胶完成。

3. Transfer gluing: when the set temperature is reached, put the aluminum frame on the conveyor belt by hand. When the front end gluing photoelectric detects the aluminum frame, the automatic gluing process starts. After there is a signal from the gluing photoelectricity, delay for a period of time, and press down the front pressing wheel to press the aluminum frame; After the front pressure roller is pressed down, the rubber cylinder will advance and the rubber nozzle will release rubber. After the start of gluing, delay for a period of time and press down the rear pressure roller. After the photo electric signal of gluing disappears, delay for a period of time, the front pressure wheel is lifted, and after the front pressure wheel is lifted, delay for a period of time, the glue cylinder stops moving and the glue nozzle stops gluing; After stopping the gluing, after a period of time, the rear pressure roller will be lifted and the gluing on one side of the aluminum frame will be completed.

之后重复传送打胶流程，将铝框剩余三边全部涂上丁基胶，铝框涂胶就全部完成。

After that, repeat the transfer and gluing process, coat the remaining three sides of the aluminum frame with butyl glue, and the gluing of the aluminum frame is completed.

因为大多数铝框为方形而少数为圆形，所以在自动中可以进行方形和圆形的切换。当为圆形框涂胶时，中间压轮压住圆框，同时皮带转动，胶嘴出胶，松开脚踏开关该过程停止。

Since most of the aluminum frames are square and a few are round, you can switch between square and round in automatic. When the round frame is coated with glue, the intermediate pressure roller presses the round frame, and the belt rotates, the glue nozzle is released, and the process stops when the foot switch is released.
